Keysight 是德科技 N9000B CXA 信号分析仪 26.5 GHz

无线电、射频、光通信等仪器维修、租赁、销售、回收一站式服务！

徐经理  15850304045

频率 无

频率选件 3, 7.5, 13.6, 26.5 GHz

标准衰减器衰减范围 50 dB

标准衰减器步进 10 dB

实时带宽选件 无

1 GHz 时的 DANL -163 dBm

分析带宽 25 MHz

1 GHz 时，1 MHz 频偏处的相位噪声 -130 dBc/Hz

1 GHz 时，10 kHz 频偏处的相位噪声 -110 dBc/Hz

1 GHz 时，30 kHz 频偏处的相位噪声 无

无杂散动态范围 无

三阶截获（TOI），1 GHz 时 无

可用应用 是

实时带宽 无

总体幅度精度 ±0.5 dB

带宽选件 10 MHz（标配），25 MHz

性能水平 ◆◆◇◇◇◇

应用——蜂窝

GSM/EDGE

LTE/LTE-Advanced

NB-IoT

W-CDMA/HSPA/HSPA+

应用——数字视频 无

应用——通用

89600 VSA 软件

模拟解调

噪声系数

相位噪声

脉冲

激励响应

EMI

MATLAB

Vector Modulation Analysis

应用——无线连通性

Bluetooth? (BR/EDR/LE4.2/5.0)

Short Range Communications (ZigBee, Z-Wave)

WLAN 802.11(a/b/g/j/p/n/ac/af/ah/ax)

信掩比 > 60 dB 时的可检测信号持续时间 无

多域带宽 无

显示视图 无

触发

电平

射频猝发

线路

外置

周期

使用频率模板触发的应用软件 无

2 GHz 时的 DANL，不配备前置放大器 无

10 GHz 时的 DANL，不配备前置放大器 -142 dBm/Hz

台式 是

选件和升级

选件

Frequency range

Bandwidth

Performance options

Calibration options

Connection Options

Generator

Portable packaging

Preamplifier

Security - PC features

Accessories

Application software

保修、校准和服务

售后升级

选件

了解详细信息: 查看配置指南

Frequency range

N9000B-503 Frequency Range, 9 kHz to 3 GHz

N9000B-507 Frequency Range, 9 kHz to 7.5 GHz

N9000B-526 Frequency Range, 9 kHz to 26.5 GHz

N9000B-513 Frequency Range, 9 kHz to 13.6 GHz

Bandwidth

N9000B-B25 Analysis Bandwidth, 25 MHz

Performance options

N9000B-FSA Fine Resolution Step Attenuator

N9000B-PFR Precision Frequency Reference

Calibration options

N9000B-UK6 Commercial Calibration Certificate With Test Data

N9000B-A6J ANSI Z540-1-1994 Calibration

N9000B-AMG Calibration + Uncertainties + Guardbanding (Accredited)

Connection Options

N9000B-CR3 Connector, Wideband IF Output

Generator

N9000B-T06 Tracking Generator, 9 kHz to 6 GHz

N9000B-T03 Tracking Generator, 9 kHz to 3 GHz

Portable packaging

N9000B-PRC Portable Configuration

Preamplifier

N9000B-P03 Preamplifier, 3 GHz

N9000B-P07 Preamplifier, 7.5 GHz

N9000B-P13 Preamplifier, 13.6 GHz

N9000B-P26 Preamplifier, 26.5 GHz

Security - PC features

N9000B-SF1 Security Features, Exclude Launching Programs

N9000B-SF2 Security Features, Prohibit Saving Results

N9000B-SSD Additional Removable Solid State Drive

N9000B-SS1 Additional removable solid state drive, Win10

Accessories

1CM113A Rack mount flange kit 177.0mm H (4U) - two flange brackets, 2015 color

1DVR001A ROM/CD-R/RW drive

1MSE001A Mouse

MLP001A Minimum loss pad, 50 to 75 ohm

1CR013A Rack Slide Kit for 11in, 14in, and 16in Mounting Holes

N9000B-AB1 Korean localization, user interface and getting started guide

N9000B-AB2 Chinese localization, user interface and getting started guide

N9000B-ABE Spanish localization, user interface and getting started guide

N9000B-ABF French localization, user interface and getting started guide

N9000B-ABJ Japanese localization, user interface and getting started guide

N9000B-AKT Russian localization, user interface and getting started guide

Application software

89601BU Update and Subscription Service, transportable license

N6171A MATLAB 软件
